MODEL NO. :
EGL MINI
4V
WEIGHING SCALE
A compact square board for tight cabinets. 63.5 × 63.5 mm, 4-volt operation, ADC 0809 (Taiwan), driver-based segment control with dual-LED support. Up to 50 hours battery backup and the standard Bobby 7777 firmware feature set.
Specifications
| MODEL | MINI 4V |
| ADC | ADC 0809 Taiwan |
| SOFTWARE | 7777 Bobby |
| PCB SIZE | 63.5 × 63.5 mm |
| PCB GRADE | 1.6 mm thickness · FR4 |
| HOLE MOUNTING SIZE | 54 × 54 mm |
| PROTECTION | Reverse battery |
| MODE FUNCTIONS | Hold / piece-counting / kg / litre |
| DISPLAY COMPATIBLE | 0.56″, 0.8″, 1″ inches |
| LED | Dual |
| RS-232 INTERFACE | NO |
Specifications
| CAPACITY | 3 cap. with 3 step accuracy |
| DUMMY ZERO | YES |
| AIR LOCKING | YES |
| AUTO ZERO | YES |
| CAL LOCK | YES |
| BUZZER PORT | YES |
| SLEEP MODE | YES |
| BATTERY VOLT IND. | YES |
| BATTERY BACKUP | Up to 50 hours |
| BATTERY SUPPORT | 4 VOLTS |
| THREE WIRE DISPLAY | NO |
| SEGMENT CONTROL | Driver-based |
Features
Built into every Eagle Weigh card.
- ✓Compact square 63.5 × 63.5 mm footprint
- ✓Driver-based segment control with dual LED
- ✓Cal-lock and buzzer port included (vs. CHOTU)
- ✓4-volt operation, up to 50 hours backup
- ✓Same Bobby 7777 feature set as the larger boards
Used in
Where this card ships.
Square-cabinet scalesCounting scalesTabletop bench scales
Compare with
Other cards in the family.
QUALITY PRODUCT
1 YEAR WARRANTY
TESTED & CALIBRATED
MOISTURE PROOF
Specify · Quote · Ship
Need the EGL MINI for your build?
Tell us the application, the capacity and the volume — we come back with a price-and-lead-time within one business day.
ModelEGL MINI
CategoryWeighing Scale PCB
OriginMade in India · Samaypur, Delhi
Warranty1 year from invoice
