EGL Set-Point Card

(3-Step or 4-Step Output)
6V
Eagle Weigh EGL Set-Point Card weighing-scale PCB
WEIGHING SCALE

The Set-Point card triggers up to four discrete outputs as the weighbridge reading crosses programmed thresholds — for automatic batch-stop, filling-line control, hopper dispense and bag-fill weigh stations. Available in 3-step and 4-step variants on the same 6 V board.

Specifications
MODELEGL Set-Point 3 / 4 Step
OUTPUTS3 or 4 relay outputs
TRIGGERUser-programmable thresholds
MODEStandard weighing + set-point overlay
FIRMWARE7777 Bobby with set-point overlay
PCB GRADE1.6 mm thickness · FR4
BATTERY SUPPORT6 VOLTS
BATTERY BACKUPUp to 50 hours
PAIRINGAny EGL indicator / terminal
RELAY ISOLATIONOptocoupler-isolated
Specifications
CAPACITY3 cap. with 3 step accuracy
DUMMY ZEROYES
AIR LOCKINGYES
AUTO ZEROYES
CAL LOCKYES
BUZZER PORTYES
SLEEP MODEYES
BATTERY BACKUPUp to 50 hours
BATTERY SUPPORT6 VOLTS
PCB GRADE1.6 mm thickness · FR4
FIRMWARE7777 Bobby (per-application)
WARRANTY1 year · Made in India
3-STEP MODECoarse / fine / cut-off
4-STEP MODEPlus pre-warning step
Features

Built into every Eagle Weigh card.

  • ✓3-step and 4-step output variants on the same board
  • ✓Automatic batch-stop for filling stations
  • ✓Programmable thresholds — coarse / fine / cut-off
  • ✓Optocoupler-isolated relay outputs
  • ✓Standard Eagle Weigh weighing functions retained
  • ✓Pairs with EGL indicators and terminals
Used in

Where this card ships.

Batch-fill stationsHopper dispensersBag-fill weigh stationsAutomated tank fills
