MODEL NO. :
CZL 611N Load Cell
40 KG
PENCIL LOADCELL
WEIGHING
A pencil load cell is a compact, slender force transducer designed to measure tension and compression loads in tight or restricted spaces.
Specifications
| FAMILY | Aluminium single-point |
| BRAND | Green Label CZL |
| MATERIAL | Anodised aluminium alloy |
| RATED OUTPUT | 2.0±0.15 mV/V |
| Combined Error (%RO) | ≤±0.03 |
Specifications
| STANDARD PACKAGING | 560 pcs |
| CAPACITY | 20 kg, 40 kg |
Features
Built into every Eagle Weigh load cell.
- ✓Single-point off-centre load compensation
- ✓Low-profile, economical, high-volume-proven
- ✓Red: + Black: – Green: Signal + White: Signal –
- ✓Length: 81 mm Width: 13 mm Height: 14 mm Weight: 32 gm
Used in
Where this load cell ships.
Retail counter scalesBench / counting / postal scalesCheck-weighersTable-top scalesElectronic Platform Scale Electronic BalanceParcel Post Scale Digital Scale
QUALITY PRODUCT
1 YEAR WARRANTY
TESTED & CALIBRATED
MOISTURE PROOF
Specify · Quote · Ship
Need the CZL 611N for your build?
Tell us the application, the capacity and the volume — we come back with a quote and lead-time within one business day.
ModelCZL 611N
CategoryLoad Cell
OriginMade in china
Warranty
